CPUSocket: LGA 1851Ethernet1 x Realtek 2.5Gb Ethernet,
ASUS LANGuardUSBRear USB (Total 8 ports):
1 x USB 20Gbps (Type-C with DP Alt Mode),
1 x USB 10Gbps (Type-A),
4 x USB 5Gbps (Type-A),
2 x USB 2.0 (Type-A),
Front USB (Total 7 ports):
1 x USB 5Gbps connector (supports USB Type-C),
1 x USB 5Gbps header (supports 2 x USB 5Gbps),
2 x USB 2.0 headers (supports 4 x USB 2.0),
Info:
USB Type-C power delivery output: max. 5V/3A,
USB_E1 ~ E4 share bandwidthChipsetIntel® Z890 ChipsetWirelessWi-Fi 7:
2x2 Wi-Fi 7 (802.11be),
Supports 2.4/5/6GHz frequency band,
Bluetooth® v5.4Memory slots Support4 x DIMM slots, max. 256GB, DDR5,
Support up to 8666+MT/s (OC)Internal I/O ConnectorsCooling:
1 x CPU Fan (4-pin),
1 x CPU OPT Fan (4-pin),
1 x AIO Pump (4-pin),
4 x Chassis Fan (4-pin),
Power:
1 x 24-pin ATX,
1 x 8-pin 12V,
1 x 4-pin 12V,
Storage:
3 x M.2 (Key M),
6 x SATA 6Gb/s,
USB:
1 x USB 5Gbps connector (supports USB Type-C),
1 x USB 5Gbps header (supports 2 x USB 5Gbps),
2 x USB 2.0 headers (supports 4 x USB 2.0),
Misc:
3 x Addressable Gen2,
1 x Aura RGB,
1 x Clear CMOS,
1 x Chassis Intrusion,
1 x COM,
1 x Front Audio (F_AUDIO),
1 x S/PDIF Out,
1 x SPI TPM (14-1 pin),
1 x System Panel (10-1 pin),
1 x Thunderbolt (USB4) headerExpansion SlotsExpansion Slots:
1 x PCIe 5.0 x16 slot,
1 x PCIe 4.0 x16 slot (supports x4 mode),
2 x PCIe 4.0 x16 slots (support x1 mode),
Storage:
3 x M.2 slots,
6 x SATA 6Gb/s portsGraphics Device1 x DisplayPort 1.4,
1 x HDMI 2.1 port,
1 x USB 20Gbps port (USB Type-C®) SoundRealtek 7.1 Surround Sound High Definition Audio CODEC,
3 x Audio jacksForm FactormATX,
9.6 x 9.6 inWarranty1 Year Warranty
