CPUSocket: LGA 1700,
Support Intel® Core⢠14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® ProcessorsEthernet1 x Realtek 2.5Gb Ethernet,
TUF LANGuardUSBRear USB (Total 6 ports):
1 x USB 20Gbps port (1 x USB Type-C®),
1 x USB 10Gbps port (1 x Type-A),
3 x USB 5Gbps ports (3 x Type-A),
1 x USB 2.0 port (1 x Type-A),
Front USB (Total 7 ports):
1 x USB 10Gbps connector (supports USB Type-C®),
1 x USB 5Gbps header (support 2 additional USB 5Gbps ports),
2 x USB 2.0 headers (support 4 additional USB 2.0 ports)ChipsetIntel® B760 ChipsetWirelessWi-Fi 6, Bluetooth v5.2Memory slots Support4 x DIMM, Max. 192GB, DDR5,
Dual Channel Memory Architecture,
Supports Intel® Extreme Memory Profile (XMP),
OptiMem IIInternal I/O ConnectorsCooling:
1 x CPU Fan (4-pin),
1 x CPU OPT Fan (4-pin),
1 x AIO Pump (4-pin),
4 x Chassis Fan (4-pin),
Power:
1 x 24-pin ATX,
1 x 8-pin 12V,
1 x 4-pin 12V,
Storage:
3 x M.2 (Key M),
4 x SATA 6Gb/s,
USB:
1 x USB 10Gbps connector (supports USB Type-C®),
1 x USB 5Gbps header (support 2 x USB 5Gbps),
2 x USB 2.0 headers (support 4 x USB 2.0),
Misc:
3 x Addressable Gen 2,
1 x Aura RGB,
1 x Clear CMOS,
1 x COM,
1 x Front Audio (AAFP),
1 x System Panel (20-3 pin, with Chassis Intrude function),
1 x Thunderbolt⢠(USB4®) headerExpansion SlotsExpansion Slots:
1 x PCIe 5.0 x16 slot,
1 x PCIe 3.0 x16 slot (supports x4 mode),
2 x PCIe 3.0 x1 slots,
Storage:
3 x M.2 slots,
4 x SATA 6Gb/s portsGraphics Device1 x DisplayPort 1.4,
1 x HDMI® 2.1 portSoundRealtek 7.1 Surround Sound High Definition Audio CODECForm FactorATX,
12 x 9.6 inWarranty1 Year Warranty
